HIGHLIGHTS
- 2 way passive speaker with dedicated controller
- Aluminium-wood hybrid enclosure
- Kevlar LF driver
- High frequency nested in custom waveguide
Downloads
Product Literature: Sonodyne Residential 2015 Product Literature: SRT Series Owners Manual: SRT 101 Product Literature
Specifications
| DESCRIPTION | 2 way shallow profile surround speaker |
|---|---|
| TRANSDUCER COMPLEMENTS: HF | 26mm silk dome neodymium magnet tweeter with waveguide |
| TRANSDUCER COMPLEMENTS: LF | 1 x 6″ Kevlar cone woofer |
| RECOMMENDED AMPLIFIER POWER | 120 W |
| NOMINAL IMPEDANCE | 8 Ohm |
| SENSITIVITY (1 w 1m) | 90 dB |
| FREQUENCY RESPONSE (-3 dB) on axis | 80 Hz ~ 20 kHz |
| FREQUENCY EXTENSION (-10 dB) | 63 Hz ~ 22 kHz |
| INPUTS | 63 Hz ~ 22 kHz |
| FINISH | Black painted |
| DIMENSIONS (HxWxD) mm | 420 x 300 x 135 |
| IN THE BOX | Wall mounting brackets |
* All specifications are subject to change due to continuous improvements
