Magnat AEH 400 ATM Pair

69,990.00

 • Design: Dolby Atmos-enabled high- performance add-on loudspeaker with direct- radiating mode.
• Equipment: 1 x 5.25″ coaxial speaker
• Power Handling (RMS / Max.): 50 / 120 watts

  • With defined dispersion characteristics for perfect Dolby Atmos surround sound

    Dolby also imposes extremely strict requirements to ensure that the demanding multi-channel procedure can generate perfect reproduction. The dispersion characteristics and position of the add-on loudspeakers are important. A subwoofer with an integrated tweeter, a so-called coaxial driver, is the best option here. The Cinema Ultra AEH 400-ATM is a coax with a 13 cm bass plus 25 mm tweeter cone and is a perfect fit, in terms of both external appearance and installation depth, on top of an LCR 100-THX ? which is also where it should be according to the Dolby guidelines. For those cases where home cinema fans prefer to mount the excellent sounding AEH 400-ATM on the wall or ceiling, we have, instead of the frequency response optimized for ceiling reflection as stipulated by Dolby, included a second crossover for linear reproduction which can be activated via a toggle switch.

    Visit the new Cinema Ultra page

    Reviews

    WHAT DO TRADE MAGAZINES SAY ABOUT THIS PRODUCT?

    Heimkino3/4-2016 (Set 5.1.4)
    Heimkino3/4-2016 (Set 5.1.4)
    areadvd.de
    areadvd.de
    07/2016
    lowbeats.de
    lowbeats.de
    04/2016 (5.1.2 SET)
    video 04/2016(5.1.2 Set)
    video 04/2016(5.1.2 Set)

    Technical Specifications

    PRINCIPLE

    Dolby Atmos-enabled high-performance add-on loudspeaker with direct-radiating mode

    DRIVERS

    1 x 5,25″ coaxial speaker

    POWER HANDLING (RMS/MAX.)

    50 / 120 watts

    SENSITIVITY (2.8V/1M)

    89 dB

    IMPEDANCE

    6 Ohms

    FREQUENCY RESPONSE

    45 ? 37.000 Hz

    CROSSOVER FREQUENCIES

    Atmos-Modus: 3.200 Hz Direct-Modus: 3.300 Hz

    RECOMMENDED AMPLIFIER OUTPUT

    20 – 120 Watts

    DIMENSIONS (WXHXD)

    280 x 150 x 188 mm

    WEIGHT

    3.7 kg

Product Type

SKU: H400TM Pr Category:
